SPECIFICATIONS

Brand Name: sennesai

Built-in Battery: No

Certification: CE

Choice: yes

Communication: WireLess

Diaphragm: S-Mall

High-concerned chemical: None

Origin: Mainland China

Package: Yes

Polar Patterns: Uni-directional

SENNESAI Model: EW100G3

Set Type: Transmitter Sets

Style: Handheld Microphone

Transducer: Dynamic Microphone

Use: Stage Performance Wireless Microphone

Ew100 g3/ wireless karaoke microphone/professional wireless microphone/karaoke microphones wireless

FEATURES:

UHF band transmission signal, the frequency range 635Mhz-695Mhz

Receiver and transmitter are equipped with LED display

The back of the receiver is equipped with 2 rubber antennas to enhance the received signal and highlight the appearance of high-grade

Contained one 6.3mm outputs and one balanced output, suitable for connecting a variety of external devices

Microphone power consumption is 130mA, using 1.5V AA*2 battery power supply, can be used for more than 6 hours

Using distance: about 190ft-260ft

Audio and data use 32bit encryption transmission and independent ID code, effectively prevent crosstalk and interference

Transmitter and receiver use 8bit encryption infrared transmission synchronization mode

Use high fidelity moving coil microphone capsule, so that your voice is more clear and real

SPECIFICATIONS

System parameters: EW300 G3

Audio frequency response: 80-17KHz

Dynamic range: ≥ 60dB

System distortion: ≤1%

Signal to noise ratio: ≥ 60dB

Ideal distance:190ft-260ft

Operating temperature range: 5 ℃ -4.5 ℃

RECEIVER

Receiver sensitivity: <2μV

Mirror suppression:> 40dB

To increase: 50μS

Audio output impedance: 600Ω

Audio output level: 0-0.5V

Use power: AC100-240V 50 / 60Hz

Power consumption: 3W

Volume: 240mm X 135mm X 42mm

TRANSMITTER

Frequency stability: ± 0.005%

Carrier output power: ≤ 30Mw

Spurious radiation suppression:>40dB

Modulation: UHF

Maximum modulation: ± 75KHz

Pickup mode: moving coil

Use power: 1.5V

Battery power consumption: <30mA
